80W Flexible Solar Panel H-Series

Applications For Motor Boats and Sailing Yachts For Yachts, Electric Boats, Cruise Ships For Buoy, Lighthouse, Deck, Boat Roof, Boat Railing For Marine transportation industry, Marine application products

Share to:

Model Number: BS80-FS-M(E)
Brand: Bright Solar
Max Power Pm(Wp): 80W
Max Working Voltage (Vmp): 20V
Solar Cell: 182*182mm/Mono
Product Dimension: 802*582*4.5mm
Cells Efficiency: 22.5%
Warranty: 3 Year

Specification Product Description Downloads

Model Number	BS80-FS-M(E)
Max Power Pm(Wp)	80W
Max Working Voltage (Vmp)	20V
Max Operating Current(Ipm)	4.00A
Open Circuit Voltage (Voc)	25V
Short Circuit Current (Isc)	4.25A
Product Size	8025824.5mm
Solar Cell	182*182mm/Mono
Efficiency	22.5%
Warranty	3 Year
Weight	2.66 KG

Features:

0-3% Flexibility
Mostly Robust construction, Rugged & Tough design
Can walk easily, Durable, Versatile
100% salt water resistant & maintenance-free, easy to install。Double encapsulated inside with DuPont ETFE surface
UV Resistance & reduce sslip risks
0~3% tolerance output power
PERC Mono solar cells or SunPower with highest performance*lP67 junction box cable output, sealed and fully waterproof*Cable
3m length cables or 2*1m with MC4 connectors304 stainless steel eyelets for easy fixing and installation Gule solution for installation
Rounded corners +plastic cover for protection
Optional:blocking diode and bypass diode , avoid shadow
Anti-Hotpot design
3 years warranty power output

Product information

Flexible solar panel H series.pdf Download
